Introduction to TECE Installation Frames
TECE installation frames are the foundation of concealed sanitary installations. These robust steel frames provide secure mounting for wall-hung toilets, washbasins, and other fixtures while hiding all plumbing connections behind the wall.
Types of TECE Installation Frames
TECEprofi Frame
The standard professional frame suitable for most applications: For professional installations, consider TECE ramka montażowa do montażu zlicowanego.
- Height adjustment: 850-1150mm
- Load capacity: 400kg
- Universal compatibility
- Integrated pipe routing
TECEprofi Compact
Designed for space-constrained installations: For professional installations, consider TECE ramka maskująca do ramki montażowej do WC.
- Reduced depth requirements
- Maintains full load capacity
- Ideal for renovation projects
- Same adjustment range
Specialty Frames
TECE offers specialized frames for:
- Corner installations
- Accessible bathrooms
- Commercial applications
- High-rise buildings
Key Technical Specifications
Load-Bearing Capacity
All TECE frames are tested and certified: For professional installations, consider TECE ramka montażowa do montażu zlicowanego.
- Standard capacity: 400kg
- Reinforced options available
- Compliance with DIN standards
- Safety factor: 3:1
Adjustment Systems
TECE frames feature precise adjustment mechanisms:
- Vertical adjustment: 300mm range
- Horizontal fine-tuning
- Depth adjustment capability
- Tool-free final adjustments
Installation Requirements
Wall Construction
Proper wall preparation is critical:
- Minimum wall thickness: 100mm
- Structural wall attachment required
- Load-bearing capacity verification
- Waterproofing for wet areas
Mounting Hardware
TECE provides comprehensive mounting solutions:
- Heavy-duty wall anchors
- Chemical anchors for concrete
- Mechanical anchors for masonry
- Steel frame fixings
Installation Process
Step 1: Wall Preparation
Prepare the installation area:
- Mark mounting positions
- Check wall structure
- Verify load-bearing capacity
- Prepare anchor points
Step 2: Frame Assembly
Assemble the frame according to specifications:
- Attach mounting brackets
- Install adjustment mechanisms
- Prepare pipe routing
- Check all connections
Step 3: Frame Mounting
Secure the frame to the wall:
- Position frame accurately
- Mark anchor positions
- Install anchors securely
- Level and plumb frame
- Tighten all fixings
Step 4: Pipe Connections
Complete plumbing connections:
- Water supply (cold and hot if required)
- Waste connections (110mm standard)
- Overflow connections
- Test all connections
Adjustment and Fine-Tuning
Height Adjustment
TECE frames allow precise height adjustment:
- Range: 850-1150mm from floor
- Incremental adjustment capability
- Locking mechanism prevents movement
- Easy access for adjustments
Final Positioning
Before wall finishing:
- Verify final fixture position
- Check alignment with other fixtures
- Ensure accessibility requirements
- Lock all adjustment mechanisms
Compatibility and Integration
Fixture Compatibility
TECE frames are compatible with:
- All TECE wall-hung toilets
- Most major sanitary brands
- Various washbasin types
- Bidet installations
System Integration
Frames integrate with:
- TECE concealed cisterns
- Flush plate systems
- Water supply systems
- Waste water systems
Quality and Certification
TECE frames meet highest standards:
- DIN EN 997 certification
- CE marking compliance
- ISO 9001 quality management
- Environmental standards (ISO 14001)
Professional Benefits
For installers and contractors:
- Standardized installation process
- Reduced installation time
- Comprehensive technical support
- Training and certification programs
- Reliable warranty coverage
Maintenance and Service
TECE frames require minimal maintenance:
- No regular servicing needed
- Corrosion-resistant materials
- Long-term stability
- Easy access for repairs
Applications
Suitable for various projects:
- Residential bathrooms
- Commercial buildings
- Hotel developments
- Healthcare facilities
- Public buildings
Conclusion
TECE installation frames provide the reliable foundation for modern concealed sanitary installations. Their robust construction, precise adjustment capabilities, and professional-grade quality make them the preferred choice for contractors and installers worldwide. Proper installation ensures long-term performance and customer satisfaction.
